The hydraulic oil model: 46# Anti-wear hydraulic oil.
Recommended hydraulic and lubricating oils for priority use:
| Specification | Application | |
| Hydraulic oil | Viscosity: 46、 68cSt (40°C) | Hydraulic system |
| Brand/specification | Mobli D、T、 E 25、26 Shell Tellus 0il 46、68 Chinese brand:46 and 68 anti-wear hydraulic oils | Hydraulic system |
| Lubricating oil | 46, 68 # anti wear hydraulic oil | Feet of moving platen Injection platform base plate |
| Grease | No. 00 lithium grease MoS2 lubricating grease | Injection components Clamping unit related points |
Different country will have different model name for hydraulic oil.
You can refer to the comparison table below:
| China | 68 anti-wear hydraulic oils | ||||
| Britain | BP Energol HLP 68 | Castro Hvspin AWS 68 | Shell Tellus 68 | ||
| American | 美浮公司 D. T.E. 26 | Esso Nuto H 68 | Texaco Rando oil HD 68 | Caltex Rando oil HD 68 | Gulf Harmony 68 AN |
| France | Alpha Acantis 68 | TotalEnergies Azolli 68 | |||
| Italy | Italian Petroleum I. P. Hydrus 68 | ||||
| Japan | Idemitsu Daphne Hydraulic Fluid 68 | Mitsubishi Diamond EP 68 |
Different models and brands of injection molding machines may have different requirements, ensuring that the selected oil can meet the working requirements of the machine is crucial.
Notes for using hydraulic oil of injection molding machine:
- Use a dedicated oil filter when you add the hydralic oil.New hydraulic oil often cannot be fully filtered. Therefore, we recommend passing through a microfilter (10 μ m) Filter hydraulic oil.
- If the oil level is low after the machine starts, it needs to be injected again.Generally, it needs to reach 3/4 to 4/5 of the fuel tank’s passenger volume.
- Although the viscosity is the same, hydraulic oils of different brands and models cannot be mixed for use.Do not mix hydraulic oil
- Do not start the hydraulic pump within approximately 3 hours after the machine’s hydraulic oil is injected to facilitate the discharge of gas from the hydraulic oil.
The above suggestions are for reference only, and the specific selection should be based on the injection molding machine model you are using and the instructions in the machine manual.
